Identity Store Activity Parameters

Early Access

Passkey Activities

Start Passkey Registration

Begins the passkey registration process.

Parameter Description Type Default
challenge The signed challenge is represented by a public key registered to the User. This value is auto-generated. String
Create User If enabled, a new User will be created as part of the passkey registration. Default behavior is disabled. Boolean ${false}
Passkey Registration Key Required - The unique ID associated with the passkey registration activity. String passkeyReg1
Passkey User Display Name Required - An informal display name associated with the User. String
Passkey User Handle A unique identifier that is used to identify the credentials of the User per relying party. This value is a base-64 encoded string of bytes with a maximum length of 64 bytes. Base-64 URL Encoded String of Bytes
Passkey User Name Required - A unique Username to identify the User. String
Registration Policy Required - The name of the registration policy. String
Relying Party ID Required - The ID of the relying party whose passkey registration configuration will be used. String
Store Name Required - The name of the Identity Store. String
User External Id Required - If the 'Create User' property is enabled, this property must be configured as a unique ID for the newly created User.

Optional - If the 'Create User' property is disabled, this property can be used to identify the User that the passkey registration applies to.		 String
User ID The unique ID automatically generated when the User is created. In the context of the 'Start Passkey Registration' activity, this ID can be used to identify the User that the passkey registration applies to. String
User Key The User Key that can be used to identify the User that the passkey registration applies to. String user1

Complete Passkey Registration

Finalizes the passkey registration process.

Parameter Description Type Default
Fail Check on Cancel If enabled, checks will fail if the end-user cancels out of the process. Default behavior is disabled. Boolean ${false}
Passkey Registration Browser Response This input parameter must be set when the passkey registration flow uses a Custom Page to collect data instead of a form.

In order to complete the passkey registration, a response from the browser must be provided. This response is returned from the Custom Page and can be entered into the 'Passkey Registration Browser Response' using variable substitution.

${_customUis.{{customPageKey}}_.currentCapture.customPageParameters.passkeyRegClientResponse.value}		 String
Passkey Registration Key The unique ID associated with the passkey registration attempt. String passkeyReg1

Start Passkey Authentication

Begins the passkey authentication process.

Parameter Description Type Default
Authentication Policy The authentication policy to use for the authentication process. String
Challenge The signed challenge is represented by a public key registered to the User. This value is auto-generated. String
Passkey Authentication Key Required - The unique ID associated with the passkey authentication activity. String passkeyAuth1
Relying Party ID Required - The ID of the relying party whose passkey registration configuration will be used. String
Store Name Required - The name of the Identity Store. String
User External ID This property can be used to identify the User that the passkey registration applies to. String
User ID The unique ID automatically generated when the User is created. In the context of the 'Start Passkey Registration' activity, this ID can be used to identify the User that the passkey registration applies to. String
User Key The User Key that can be used to identify the User that the passkey authentication applies to. String user1

Complete Passkey Authentication

Finalizes the passkey authentication process.

Parameter Description Type Default
Fail Check on Cancel If enabled, checks will fail if the end-user cancels out of the process. Default behavior is disabled. Boolean ${false}
Passkey Authentication Browser Response This input parameter must be set when the passkey registration flow uses a Custom Page to collect data instead of a form.

In order to complete the passkey authentication, a response from the browser must be provided. This response is returned from the Custom Page and can be entered into the 'Passkey Authentication Browser Response' using variable substitution.

${_customUis.{{customPageKey}}.currentCapture.customPageParameters.passkeyAuthClientResponse.value}		 STRING
Passkey Authentication Key The unique ID associated with the passkey authentication attempt. STRING passkeyAuth1

Appkey Activities

Start Appkey Registration

Starts the Appkey registration process.

Parameter Description Type Default
Appkey Registration Key The unique ID associated with the Appkey registration activity. String appkeyReg1
Appkey User Name An informal display name associated with the User. String
Challenge The signed challenge is represented by a public key registered to the User. This value is auto-generated. String
Create User If enabled, a new User will be created as part of the passkey registration. Default behavior is disabled. Boolean ${false}
Registration Policy The name of the registration policy. String
Relying Party ID The ID of the relying party whose Appkey registration configuration will be used. String
Server Data This field can contain optional session data that a relying party can associate with the request. String
Store Name The name of the Identity Store. String
User External ID Required - If the 'Create User' property is enabled, this property must be configured as a unique ID for the newly created User.
Optional- If the 'Create User' property is disabled, this property can be used to identify the User that the Appkey registration applies to.		 String
User ID The unique ID automatically generated when the User is created. In the context of the 'Start Appkey Registration' activity, this ID can be used to identify the User that the Appkey registration applies to. String
User Key TThe User Key that can be used to identify the User that the Appkey registration applies to. String user1

Complete Appkey Registration

Completes the Appkey registration process.

Parameter Description Type Default
Appkey Name A friendly name for the Appkey that can be supplied in cases where the name is not supplied by the device. String
Appkey Registration Browser Response In order to complete the Appkey registration, a response from the browser must be provided. This response is returned from the Custom Page and can be entered into the 'Appkey Registration Browser Response' using variable substitution. ${_customUis.{{customPageKey}}_.currentCapture.customPageParameters.appkey.value} String
Appkey Registration Key The unique ID associated with the Appkey registration attempt. String appkeyReg1
Fail Check On Cancel If enabled, checks will fail if the end-user cancels out of the process. Default behavior is disabled. Boolean ${false}
List of Screens A list of screens to display to the end-user. List [String] [notify]
Starting Component ID The ID of the starting component. String appkey
UI Component ID The ID of the UI component. String notify

Start Passkey Authentication

Starts the Appkey authentication process.

Parameter Description Type Default
Appkey Authentication Key The unique ID associated with the Appkey registration activity. String appkeyAuth1
Authentication Policy The name of the authentication policy. String
Challenge The signed challenge is represented by a public key registered to the User. This value is auto-generated. String
Relying Party ID The ID of the relying party whose Appkey authentication configuration will be used. String
Server Data This field can contain optional session data that a relying party can associate with the request. String
Store Name The name of the Identity Store. String
User External ID This property can be used to identify the User that the Appkey authentication applies to. String
User ID The unique ID automatically generated when the User is created. In the context of the 'Start Appkey Authentication' activity, this ID can be used to identify the User that the appkey authentication applies to. String
User Key The User Key that can be used to identify the User that the Appkey authentication applies to. String user1

Complete Appkey Authentication
Parameter Description Type Default
Appkey Name A friendly name for the Appkey that can be supplied in cases where the name is not supplied by the device. String
Appkey Registration Browser Response In order to complete the Appkey authentication, a response from the browser must be provided. This response is returned from the Custom Page and can be entered into the 'Appkey Authentication Browser Response' using variable substitution. ${_customUis.{{customPageKey}}_.currentCapture.customPageParameters.appkey.value} String
Fail Check On Cancel If enabled, checks will fail if the end-user cancels out of the process. Default behavior is disabled. Boolean ${false}

Appkey Registration

Performs an all-in-one silent Appkey device and biometric registration.

Parameter Description Type Default
Appkey Registration Key The unique ID associated with the Appkey registration activity. String appkeyReg1
Appkey User Name An informal display name associated with the User. String
List of Screens The list of screens to show to the user. String [List] [silent-registration]
Challenge The signed challenge is represented by a public key registered to the User. This value is auto-generated. String
Create User If enabled, a new User will be created as part of the passkey registration. Default behavior is disabled. Boolean ${false}
Registration Policy The name of the registration policy. String
Relying Party ID The ID of the relying party whose Appkey registration configuration will be used. String
Server Data This field can contain optional session data that a relying party can associate with the request. String
Starting Component ID The unique ID of the starting component. String appkey
Store Name The name of the Identity Store. String
UI Component ID The unique ID of the UI component. String silent-registration
User External ID Required - If the 'Create User' property is enabled, this property must be configured as a unique ID for the newly created User.
Optional- If the 'Create User' property is disabled, this property can be used to identify the User that the Appkey registration applies to.		 String
User ID The unique ID automatically generated when the User is created. In the context of the 'Start Appkey Registration' activity, this ID can be used to identify the User that the Appkey registration applies to. String
User Key TThe User Key that can be used to identify the User that the Appkey registration applies to. String user1

Appkey Authentication

Performs an all-in-one silent Appkey device and biometric authentication.

Parameter Description Type Default
Appkey Authentication Key The unique ID associated with the Appkey registration activity. String appkeyAuth1
Authentication Policy The name of the authentication policy. String
Challenge The signed challenge is represented by a public key registered to the User. This value is auto-generated. String
List of Screens The list of screens to display to the end-user. List [String] [silent-authentication]
Relying Party ID The ID of the relying party whose Appkey authentication configuration will be used. String
Server Data This field can contain optional session data that a relying party can associate with the request. String
Starting Component ID The unique identifier of the starting component String appkey
Store Name The name of the Identity Store. String
User External ID This property can be used to identify the User that the Appkey authentication applies to. String
User ID The unique ID automatically generated when the User is created. In the context of the 'Appkey Authentication' activity, this ID can be used to identify the User that the appkey authentication applies to. String
User Key The User Key that can be used to identify the User that the Appkey authentication applies to. String user1

Deregister Appkey

Deregisters an Appkey on the client and server.

Parameter Description Type Default
Appkey Deregistration Key The unique ID associated with the Appkey deregistration activity. String appkeyDereg1
Device Id The ID of the device that the Appkey is associated with. String
List of Screens The list of screens to display to the end-user. List [String] [deregister]
Relying Party ID The ID of the relying party whose Appkey configuration will be used. String
Starting Component ID The unique identifier of the starting component String appkey
Store Name The name of the Identity Store. String
Types The Appkey type to deregister. Supported values are 'DEVICE, 'BIOMETRIC' and 'ALL'. List [String]
UI Component ID The ID of the UI component. String deregister
User External ID This property can be used to identify the User that the Appkey deregistration applies to. String
User ID The unique ID automatically generated when the User is created. In the context of the 'Deregister Appkey' activity, this ID can be used to identify the User that the appkey authentication applies to. String
User Key The User Key that can be used to identify the User that the Appkey authentication applies to. String user1

Deregister Client Appkey

Deregisters an Appkey on the client only.

Parameter Description Type Default
List of Screens The list of screens to display to the end-user. List [String] [deregister-client]
Relying Party ID The ID of the relying party whose Appkey configuration will be used. String
Starting Component ID The unique identifier of the starting component String appkey
Store Name The name of the Identity Store. String
Types The Appkey type to deregister. Supported values are 'DEVICE, 'BIOMETRIC' and 'ALL'. List [String]
UI Component ID The ID of the UI component. String deregister-client

User Activities

Add User

This activity can be used to add a User to a specified Identity Store. The 'User External ID' is used to identify the newly added User. If no External ID is supplied, an ID will be generated automatically. An additional 'User ID' is also generated automatically by TrustX upon the creation of a new User and can be used for identifying a User.

Parameter Description Type Default
Store Name Required - Represents the Identity Store that the User will be added to. String
User Attributes <String,String>< A key-value pair of additional optional attributes used to describe the User.
User Date of Birth The User's date of birth in the format: "yyyy-mm-dd" Date
User Email The User's email address in the format: "example@domain.com" String
User External ID A unique User ID. If no ID is required, an external ID will be generated automatically by TrustX. String
User First Name The first name of the User. String
User Key Required - A key used to identify the User. String user1
User Last Name The last name of the User. String
User Locale - Country The User country. String
User Locale - Language An two-letter [ISO-639](https://www.iso.org/iso-639-language-code) formatted language tag. String
User Locale - Variant A variant subtag of the User country. 5-8 letters or 4 characters starting with a digit, separated by hyphens. String
User Nationalities The nationality of the User. String
User Status The User status indicates whether the User is in a pending, active, locked or disabled state. String
User Timezone The timezone of the User Country. This value must be in line with [TZDB](https://www.iana.org/time-zones) code format.

Example: EST.		 String
User Type An optional parameter used for organizing Users into different types. A maximum of 64 characters is allowed. String

Get User

Returns information regarding the specified User.

Parameter Description Type Default
Store Name Required - Represents the Identity Store that the User belongs to. String
User External ID The External ID of the User to be returned. String
User ID The ID of the User to be returned. String
User Key The User Key of the User to be returned. String user1

Update User

This activity can be used to update various attributes of a User.

It is not possible to update the locking status of a User when using this activity. For this functionality, use the Lock User and Unlock User activities.
Parameter Description Type Default
Store Name Required - Represents the Identity Store that the User will be added to. String
User Attributes <String,String>< A key-value pair of additional optional attributes used to describe the User.
User Date of Birth The User's date of birth in the format: "yyyy-mm-dd" Date
User Email The User's email address in the format: "example@domain.com" String
User External ID Can be used to update the External ID of the User. String
User First Name The first name of the User. String
User Key Required - A key used to identify the User. String user1
User Last Name The last name of the User. String
User Locale - Country The User country. String
User Locale - Language An [ISO-639](https://www.iso.org/iso-639-language-code) formatted language tag. String
User Locale - Variant A variant subtag of the User country. 5-8 letters or 4 characters starting with a digit, separated by hyphens. String
User Nationalities The nationality of the User. String
User Status The User status indicates whether the User is in a pending, active, locked or disabled state. String
User Timezone The timezone of the User Country. This value must be in line with [TZDB](https://www.iana.org/time-zones) code format.

Example: EST.		 String
User Type An optional parameter used for organizing Users into different types. A maximum of 64 characters is allowed. String

Delete User

Deletes a User from an Identity Store. Requires one of the following identifiers to identify the User; User External ID, User ID, or User Key.

Parameter Description Type Default
Store Name Required - Represents the Identity Store that the User belongs to. String
User External ID The External ID of the User to be deleted. String
User ID The ID of the User to be deleted. String
User Key The User Key of the User to be deleted. String user1

Lock User

This activity will place the specified User in a hard lock status. This will take precedence over any temporary lock placed on the User at the Identity Store level.

Parameter Description Type Default
Store Name Required - Represents the Identity Store of the User. String
User External ID The External ID of the User to be locked. String
User ID The ID of the User to be locked. String
User Key The User Key of the User to be locked. String user1

Unlock User

This activity will unlock the specified User. All locks, including hard and temporary locks will be removed and the User will be returned to an active status.

Parameter Description Type Default
Store Name Required - Represents the Identity Store of the User. String
User External ID The External ID of the User to be unlocked. String
User ID The ID of the User to be unlocked. String
User Key The User Key of the User to be unlocked. String user1

Add Face Image to User

Adds a face image to the specified User.

Parameter Description Type Default
Face Key Required - This represents the key of the face image to be added. String face1
Store Name Required - Represents the Identity Store of the User. String
User External ID The External ID of the User. String
User ID The ID of the User. String
User Key The User Key of the User. String user1

Match Face Image to User

Performs a face match between a live image and the image associated with a User.

Parameter Description Type Default
Error navigation screen The screen that is shown when an error occurs. String instructions
Exception On Max Attempts Exceeded If enabled, an exception will be thrown when the alotted maximum match attempts is exceeded. Boolean ${true}
Face Key Required - This represents the key of the face image that will be matched against the User face image. String face1
Max Attempts The maximum number of match attempts before an exception is thrown. Integer
Store Name Required - Represents the Identity Store of the User. String
User External ID The External ID of the User. String
User ID The ID of the User. String
User Key The User Key of the User. String user1

TOTP Activities

Start TOTP Registration

Starts the TOTP registration process.

Parameter Description Type Default
Store Name The name of the Identity Store that the TOTP registration attempt applies to. String
TOTP Policy The name of the TOTP policy that will be used in the registration attempt. String
TOTP Registration Key The key used to identify the TOTP registration attempt. String totpReg1
User External ID This property can be used to identify the User that the TOTP registration applies to. String
Store Name Required - Represents the Identity Store of the User. String
User External ID The External ID of the User. String
User ID The unique ID automatically generated when the User is created. In the context of the 'Start TOTP Registration' activity, this ID can be used to identify the User that the TOTP registration applies to. String
User Key The User Key that can be used to identify the User that the TOTP registration applies to. String user1

Complete TOTP Registration

Completes the TOTP registration process and performs initial authentication.

Parameter Description Type Default
Authentication Code Represents the submitted TOTP code. String
Steps Allowed The number of previously generated TOTPs that will be accepted as valid. Integer 1
TOTP Registration Key The key used to identify the TOTP registration attempt. String totpReg1

TOTP Authentication

Performs authentication against TOTP.

Parameter Description Type Default
Authentication Code Represents the submitted TOTP code. String
Steps Allowed The number of previously generated TOTPs that will be accepted as valid. Integer 1
Store Name The name of the Identity Store that the TOTP authentication attempt applies to. String
TOTP Policy The name of the TOTP policy that will be used in the authentication attempt. String
TOTP Authentication Key The key used to identify the TOTP authentication attempt. String totpReg1
User External ID This property can be used to identify the User that the TOTP authentication applies to. String
Store Name Required - Represents the Identity Store of the User. String
User External ID The External ID of the User. String
User ID The unique ID automatically generated when the User is created. In the context of the 'TOTP Authentication' activity, this ID can be used to identify the User that the TOTP registration applies to. String
User Key The User Key that can be used to identify the User that the TOTP authentication applies to. String user1

Get TOTP

Retrieves the current TOTP registered to an Identity Store User given the User ID and Identity Store.

Parameter Description Type Default
Store Name The name of the Identity Store of the User. String
TOTP Policy The TOTP policy that was used when registering the TOTP. String
User External ID This field can be used to identify the Idenity Store User that was used to register the TOTP. String
User ID This field can be used to identify the Idenity Store User that was used to register the TOTP. String
User Key This field can be used to identify the Idenity Store User that was used to register the TOTP. String user1

Deregister TOTP

Deregisters the current TOTP from a given Identity Store User.

Parameter Description Type Default
Store Name The name of the Identity Store of the User. String
TOTP Policy The TOTP policy that was used when registering the TOTP. String
User External ID This field can be used to identify the Idenity Store User that was used to register the TOTP. String
User ID This field can be used to identify the Idenity Store User that was used to register the TOTP. String
User Key This field can be used to identify the Idenity Store User that was used to register the TOTP. String user1

Push Notification Activities

TrustX Push Notification

Early Access

Sends a TrustX push notification to the Identity Store User.

Parameter Description Type Default
Localized Message Arguments Optional list of strings to be inserted into the localised message. Either a title/message or a localised title/message must be supplied, not both or neither. List[String]
Localized Message Key Optional. Reference to a localised title in the device application. String
Localized Title Arguments Optional list of strings to be inserted into the localised title. List[String]
Localized Title Key Optional. Reference to a localised title in the device application. String
Message Mandatory. Message to be displayed. String
Monitor Push Notification Process If true then the status of the push notification Process Instance is monitored so that the customer can poll and wait for it to complete. Boolean ${true}
Push Notification Parameters Optional map of strings supplied in the push notification to the device application. List[String]
Push Notification Process Definition Name Optional. The name of the Process Definition which is started for the user when they accept the push notification. Either a process definition name and version, or a tag must be supplied, not both or neither. String
Push Notification Process Definition Tag Optional. The tag of the Process Definition which is started for the user when they accept the push notification. Either a process definition name and version, or a tag must be supplied, not both or neither. String
Push Notification Process Parameters Optional map of strings to be supplied to the push notification process when it is created. List[String]
Relying Party ID Mandatory. The Appkey relying party which references the customer application to which the push notification(s) will be sent. String
Retry Hint Duration (Seconds) Optional. Default value of 60 and a maximum allowed value of 1000. A value of 0 or less indicates that retries are disabled. Indicates for how long to retry sending the push if the service is down or busy. Integer ${60}
Store Name Mandatory. The Identity Store containing the user String
Time To Live (Seconds) Mandatory. Time to live of the push notification in seconds. Minimum valid value of 60 and a maximum of 2419200 (28 days). Integer
Title Mandatory. Title to be displayed. String
User External ID Optional. External (customer) ID of the user. String
User ID Optional. Internal ID of the user. String
User Key Optional. TrustX reference key for the user. String

Generic Push Notification

Early Access

Sends a generic push notification to the Identity Store User.

Parameter Description Type Default
Localized Message Arguments Optional list of strings to be inserted into the localised message. Either a title/message or a localised title/message must be supplied, not both or neither. List[String]
Localized Message Key Optional. Reference to a localised title in the device application. String
Localized Title Arguments Optional list of strings to be inserted into the localised title. List[String]
Localized Title Key Optional. Reference to a localised title in the device application. String
Message Mandatory. Message to be displayed. String
Push Notification Parameters Optional map of strings supplied in the push notification to the device application. List[String]
Relying Party ID Mandatory. The Appkey relying party which references the customer application to which the push notification(s) will be sent. String
Retry Hint Duration (Seconds) Optional. Default value of 60 and a maximum allowed value of 1000. A value of 0 or less indicates that retries are disabled. Indicates for how long to retry sending the push if the service is down or busy. Integer ${60}
Store Name Mandatory. The Identity Store containing the user String
Time To Live (Seconds) Mandatory. Time to live of the push notification in seconds. Minimum valid value of 60 and a maximum of 2419200 (28 days). Integer
Title Mandatory. Title to be displayed. String
User External ID Optional. External (customer) ID of the user. String
User ID Optional. Internal ID of the user. String
User Key Optional. TrustX reference key for the user. String

Wait On Push Notification

Early Access

Suspends the current Process Instance until the child Process Instance is completed.

Parameter Description Type Default
List of Screens A list of screens to display to the user. List[String] ["wait-init"]
Polling Error Retry Count Optional. Optional. The number of retries before a timeout occurs. This value represents the number of retries and not the number of attempts. Integer ${5}
Polling Interval (ms) Integer ${500}
Polling URL Mandatory. The status polling URL for the push notification Process Instance. String ${_pollingUrl}
Starting Component ID The name of the step ID for this activity. String push-notification-wait
UI Component ID The name of the screen used to excute this activity. String wait-init

Preferred Device Activities

IDS Get Preferred Device Info v1

Early Access

Parameter Description Type Default
List of Screens A list of screens to display to the user. List[String] ["appkey-device-id"]
Relying Party ID Mandatory. The customer’s appkey relying party which identifies the type of device application. String
Starting Component ID The name of the step ID for this activity. String appkey-device-id
Store Name Mandatory. The Identity Store containing the user. String
UI Component ID The name of the screen used to excute this activity. String appkey-device-id
User Key TrustX reference key for the user. String user1

IDS Set Preferred Device Info v1

Early Access

Parameter Description Type Default
List of Screens A list of screens to display to the user. List[String] ["appkey-device-id"]
Relying Party ID Mandatory. The customer’s appkey relying party which identifies the type of device application. String
Starting Component ID The name of the step ID for this activity. String appkey-device-id
Store Name Mandatory. The Identity Store containing the user. String
UI Component ID The name of the screen used to excute this activity. String appkey-device-id
User Key TrustX reference key for the user. String user1

IDS Clear Preferred Device v1

Early Access

Parameter Description Type Default
Relying Party ID Mandatory. The customer’s appkey relying party which identifies the type of device application. String
Store Name Mandatory. The Identity Store containing the user. String
User Key TrustX reference key for the user. String user1
Type to search, ESC to discard
Type to search, ESC to discard
Type to search, ESC to discard
Next to read:
Watchlist Activity Parameters
Edit on GitHub
On This Page
Identity Store Activity ParametersPasskey ActivitiesStart Passkey RegistrationComplete Passkey RegistrationStart Passkey AuthenticationComplete Passkey AuthenticationAppkey ActivitiesStart Appkey RegistrationComplete Appkey RegistrationStart Passkey AuthenticationComplete Appkey AuthenticationAppkey RegistrationAppkey AuthenticationDeregister AppkeyDeregister Client AppkeyUser ActivitiesAdd UserGet UserUpdate UserDelete UserLock UserUnlock UserAdd Face Image to UserMatch Face Image to UserTOTP ActivitiesStart TOTP RegistrationComplete TOTP RegistrationTOTP AuthenticationGet TOTPDeregister TOTPPush Notification ActivitiesTrustX Push NotificationGeneric Push NotificationWait On Push NotificationPreferred Device ActivitiesIDS Get Preferred Device Info v1IDS Set Preferred Device Info v1IDS Clear Preferred Device v1
